75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE

Brand Name:	WINLEY
Model Number:	D-100/12.47
MOQ:	1unit
Price:	$1000-$10000
Packaging Details:	Plywood case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ISO

Transformer Type:

Pad Mounted, Compartmental-Type II

Capacity:

100Kva

Primary Voltage:

12470GrdY/7200

Secondary Voltage:

240/120V (L-N-L)

Feed Type:

Loop Feed

Cooling Class:

KNAN; Self-Cooled

Efficiency:

99.00%

Temperature Rise:

Supply Ability:

1000set/month

Highlight:

12.4 KV Pad Mounted Electrical Transformer

120V Pad Mounted Electrical Transformer

75kva Pad Mounted Electrical Transformer

Product Description

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE

The single phase pad mounted transformers WINLEY produce fully comply with and exceed ANSI, DOE, IEEE and CSA standards, with a rated capacity range of 10KVA-250KVA and a voltage of up to 34.5kV, with a monthly delivery capacity of more than 600 units.

product details

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 0

Main data

Transformer Type	Pad Mounted, Compartmental-Type II
Transformer Feed Type	Loop Feed
Phase	Single Phase
Capacity	100 KVA
Vector Group	II6
Primary Voltage	12470GrdY/7200
Secondary Voltage	240/120V (L-N-L)
Frequency	60 Hz
Temperature Rise	65°C
Insulation Rating	Class E Insulation - 120°C, 248°F
Cooling Class	KNAN; Self-Cooled
Efficiency Standard(s)	Meets DOE 2016 Standards, Meets ANSI/IEEE Standards
K-Factor Rating (Harmonic Mitigation)	K-1 (Standard)
Winding Material	Copper
Ambient Temperature Rating	40°C
Sound Level	51 dBA
Tank Material	Coated Steel
Dimensions*	35''-W x 36''-D x 36''-H
Weight*	1,140 lb
Efficiency	99.00%
No Load Loss (in watts)*	+/- 270W
Load Loss (in watts)*	+/- 1,100W

Product drawings

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 1

Feature

Two externally clamped universal high-voltage bushing wells for loop feed operation or one externally clamped bushing well for radial feed operation
Three externally clamped low-voltage bushings with threaded copper studs, including a fully insulated neutral terminal with removable ground strap
Embossed bushing mounts; Recessed oil compartment bottom
Threaded, flush mounted stainless steel lifting provisions
Automatic pressure relief device
Electrical grade mineral oil with oxidation inhibitor
Removable hood with corrosion resistant stainless steel hinge pins and barrels
Mild steel enclosure and detachable sill fastened with stainless steel hardware
Front panel accessory mounting bracket;
Domed top surfaces on hood and oil compartment to prevent water retention
Oil fill/oil level plug; Oil drain plug; Tank grounding provisions
Corrosion resistant locking assembly with captive penta-head security bolt, floating nut and padlock provision
Decal or stenciled bushing designations
Laser engraved anodized aluminum nameplate
Meets or exceeds current ANSI, IEEE, NEMA, CSA, and DOE standards as applicable

Specification

Single phase Pad mounted Transformer Specification
Rating	High voltage(kV)	No Load Loss	On load Loss	Height	Depth	Width	Oil Weight(kg)	Total Weight(kg)
(kVA)	High voltage(kV)	No Load Loss	On load Loss	(mm)	(mm)	(mm)	Oil Weight(kg)	Total Weight(kg)
15 kVA	34.5/19.92 13.8/8 13.2/7.6 12.47/7.2 or others	50	195	840	740	610	45	294
25 kVA		80	290	840	740	610	68	362
37.5 kVA		106	360	840	760	610	75	476
50 kVA		135	500	840	810	610	93	553
75 kVA		190	650	840	860	610	132	672
100 kVA		280	1010	910	1200	965	230	714
167 kVA		435	1530	1000	1200	965	265	913
250 kVA		550	2230	1250	1300	1430	325	1106

Optional Accessories

Production process

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 3

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 4

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 5

75kva 1 Phase Pad Mounted Electrical Transformer Oil Immersed 12.4 KV To 120V aNSI IEEE 6

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
