 304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva

Brand Name: WINLEY
Model Number: D-250/5
MOQ: 1unit
Price: $1000-$10000
Packaging Details: Plywood case
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE,ISO
Phase:
Single Phase
Rated Capacity:
250Kva Or Customized
Primary Voltage:
4160GrdY/2400
Secondary Voltage:
240/120V
Temperature Rise:
65°C
Frequency:
60 Hz
Winding Material:
Copper
Efficiency:
99.20%
Supply Ability:
1000set/month
Highlight:

Single Phase Pad Mounted Transformer

,

75kva Pad Mounted Transformer

,

250Kva Pad Mounted Transformer

Product Description

304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva





Product detail



 304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva 0





Main data



Transformer Type Pad Mounted, Compartmental-Type
Transformer Configuration Liquid Filled Pad Mounted
Transformer Feed Type Loop Feed
Phase Single Phase
Capacity 250
Primary Voltage 4160GrdY/2400
Secondary Voltage 240/120V (L-N-L)
Secondary Phasor Dual Winding Single Phase
Frequency 60 Hz
Temperature Rise 65°C
Cooling Class ONAN; Self-Cooled
Efficiency Meet DOE 2016 Standard
Winding Material Copper
Ambient Temperature Rating 40°C
Sound Level 55 dBA
Elevation (Altitude) 3300ft (1000 meters) Above Sea Level
Tank Material 304 Stainless Steel
Cabinet Material 304 Stainless Steel
Base Platform Material 304 Stainless Steel
Dimensions* 36 x 54 x 39
Weight* 2,250 lb
Ratings Complies with ANSI / IEEE #C57.12.00
Efficiency 99.20%



Drawing



 304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva 1



Feature



1)single phase pad mounted transformer tank coating exceeds C57,12.8 and C57,12.29. Full compliance with IEEE C57.12.28 enclosure integrity standards.
2)Two externally clamped universal high-voltage bushing wells for loop feed operation or one externally clamped bushing well for radial feed operation .
3)Three externally clamped low-voltage bushings with threaded copper studs, including a fully insulated neutral terminal with removable ground strap .
4)Embossed bushing mounts; Recessed oil compartment bottom.
5)Threaded, flush mounted stainless steel lifting provisions.
6)Automatic pressure relief device.
7)Electrical grade mineral oil with oxidation inhibitor.
8)Removable hood with corrosion resistant stainless steel hinge pins and barrels Mild steel enclosure and detachable sill fastened with stainless steel hardware Front panel accessory mounting bracket.
9)Domed top surfaces on hood and oil compartment to prevent water retention .
10)Oil fill/oil level plug; Oil drain plug; Tank grounding provisions.
11)Corrosion resistant locking assembly with captive penta-head security bolt, floating nut and padlock provision.



Specification



25kva-500kva single phase pad mounted transformer
Rated Cap acity(kVA) High Low Voltage(v) Connection Symbol Standard Short-circuit impedance(%) Efficiency
Voltage(v) (%)
25 4160 7200 12000 12470 13200 13800 19920 24940 34500 110 220 230 400 480 II0,II6 IEEE/ANSI/ DOE 1.0-4.5% 98.95
37.5 99.05
50 99.11
75 99.19
100 99.25
167 99.33
250 99.39
333 99.43
500 99.49



Accessories



 304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva 2



Production process



50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 2

50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 3

 304 Stainless Steel Tank Single Phase Pad Mounted Transformer oil immersed 50kva 75kva 100kva 250Kva 5

50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 4



FAQ



1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
