Single Phase Pad Mounted Transformer

25Kva single phase Pad Mounted Transformer Oil Immersed Distribution 10KV

All Category

Three Phase Isolation Transformer

Three Phase Pad Mounted Transformer

Single Phase Pad Mounted Transformer

Industrial Control Transformer

Single Phase Control Transformer

Toroidal Isolation Transformer

Three Phase Dry Type Transformer

Three Phase Reactor

Mr. Steven

steven@winley-electric.com

86-18650108051

Contact Now

25Kva single phase Pad Mounted Transformer Oil Immersed Distribution 10KV

Brand Name:	WINLEY
Model Number:	25KVA
MOQ:	1unit
Price:	$1000-$150000
Packaging Details:	Plywood case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ISO

Phase:

Single Phase

Cooling Method:

ONAN; Self-Cooled

Frequency:

Insulation Level:

Primary Voltage:

12470GrdY/7200

Secondary Voltage:

120/240

Temperature Rise:

Efficiency:

Supply Ability:

1000set/month

Highlight:

Oil Immersed Distribution Transformer 10KV

Oil Immersed Pad Mount Transformer

25Kva Oil Immersed Transformer

Product Description

25Kva Pad Mount Transformer Oil Immersed Distribution

Feature

1)single phase pad mounted transformer tank coating exceeds C57,12.8 and C57,12.29. Full compliance with IEEE C57.12.28 enclosure integrity standards.
2)Two externally clamped universal high-voltage bushing wells for loop feed operation or one externally clamped bushing well for radial feed operation
3)Three externally clamped low-voltage bushings with threaded copper studs, including a fully insulated neutral terminal with removable ground strap
4)Embossed bushing mounts; Recessed oil compartment bottom
5)Threaded, flush mounted stainless steel lifting provisions
6)Automatic pressure relief device
7)Electrical grade mineral oil with oxidation inhibitor
8)Removable hood with corrosion resistant stainless steel hinge pins and barrels Mild steel enclosure and detachable sill fastened with stainless steel hardware Front panel accessory mounting bracket.
9)Domed top surfaces on hood and oil compartment to prevent water retention
10)Oil fill/oil level plug; Oil drain plug; Tank grounding provisions
11)Corrosion resistant locking assembly with captive penta-head security bolt, floating nut and padlock provision

25Kva single phase Pad Mounted Transformer Oil Immersed Distribution 10KV 0

25Kva single phase Pad Mounted Transformer Oil Immersed Distribution 10KV 1

Specification

Rated power(KVA)	High	H.V. Tap	Low	Short-Circuit	No-load loss(W)	On-load loss(W)	No load current(%)
Rated power(KVA)	Voltage	range	Voltage	Impedance(%)	No-load loss(W)	On-load loss(W)	No load current(%)
5	12.47 13.2 13.8 14.4	±5% ±2x2.5%	120-240/240-480 /347/600	2.5	35	145	4
10					55	260	3.5
16					65	365	3.2
20					80	430	3
30					100	625	2.8
40					125	775	2.5
50					150	950	2.3
63					180	1125	2.1
80					200	1400	2
100					240	1650	1.9
167					285	1950	1.8
250					365	2365	1.7

Production process

50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 2

50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 3

13.2kv 480V Secondary Voltage Single Phase Pad Mounted Transformer Oil Type 250kVA 5

50kva Single Phase Pad Mounted Transformer Oil Type 13200v To 240v 4

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
