100KVA Single Phase Pad Mounted Transformer 7200V 12470V

Basic Information
Place of Origin: CHINA
Brand Name: WINLEY
Certification: ISO,CE
Model Number: 100KVA
Minimum Order Quantity: 1
Price: $20-$60,000
Packaging Details: Plywood case
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 1000pcs per month
Detail Information
Usage: Power Type: Pad-mounted
Rated Capacity: 100KVA Frequency: 60Hz
Material: Copper Standard: ANSI /IEEE
Voltage: 7200V 12470V Cooling Method: ONAN
High Light:

100KVA Single Phase Pad Mounted Transformer


7200V Single Phase Pad Mounted Transformer


12470V Single Phase Pad Mounted Transformer

Product Description

100KVA Single Phase Oil Type Transformer Pad Mounted 7200V 12470V



• Meet or exceeds ANSI®, IEEE® standards
• Meets DOE Energy Efficiency Standard 10 CFR Part 431 for distribution transformers
• Tank coating exceeds IEEE Std C57.12.28™-2005 and IEEE Std C57.12.29™-2005 standards (stainless steel units only)
• Full compliance with IEEE Std C57.12.28™-2005 standard enclosure integrity requirements
• Laser engraved nameplate
• Recessed stainless steel lifting provisions
• Tank grounding provisions
• Automatic pressure relief device
• Electrical grade mineral oil
• Hinged door with stainless steel hinge pins and barrels
• Floating lock pocket for easy alignment
• Captive stainless steel pentahead door locking bolt
• Oil fill and drain provisions
• Removable sill
• Welded domed tank cover
• High-voltage bushing wells - 200 A



167KVA Single Phase Oil Type Transformer Pad Mounted 24940V 14400V 0




kVA: 10-167
Primary Voltage: 2400-19,920 V
Secondary Voltage: 120-600 V
• One piece high-voltage bushings
• High-voltage bushing wells with removable studs
• Envirotemp™ FR3™ fluid where less-flammable fluid is required and where superior enviromental characteristics are desired
• Special designs to meet international specifications are also available
• Loadbreak switches
• Drain/sampling valve
• Pressure vacuum gauge
• Liquid level gauge
• Temperature gauge


2500KVA Three Phase Oil Type Transformer Pad mounted Live Front Dead Front 0

2500KVA Three Phase Oil Type Transformer Pad mounted Live Front Dead Front 1

100KVA Single Phase Pad Mounted Transformer 7200V 12470V 3
