50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified

Brand Name:	WINLEY
Model Number:	D-50/4.16
MOQ:	1unit
Price:	$1000-$10000
Packaging Details:	Plywood case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

UL/cUL, CE, ISO

Transformer Type:

Pole Mounted Transformer

Phase:

Single

Capacity:

50 KVA

Primary Voltage:

4160Y/2400

Secondary Voltage:

120/240V (L-N-L)

Frequency Rise:

100Hz Or Customized

Cooling Class:

KNAN; Self-Cooled

Efficiency Standard(s):

DOE 2016 , CSA , ANSI/IEEE

Supply Ability:

1000set/month

Product Description

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified

WINLEY is a trusted, highly specialized manufacturer of pole mounted transformers.Available in ratings from 10-333 kVA,Meeting ANSI/IEEE and other standards.Get a Quote in Minutes!

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 0

WINLEY's pole-mounted transformers, UL/cUL certified, exceed ANSI, IEEE, CSA, IEC60076 standards. Our safe, stable, and efficient designs cut operational costs for reliable power solutions.

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 1

Main Data

Transformer Type	Overhead Distribution Transformer, Conventional Type
Phase	Single Phase
Capacity	50 KVA
Primary Voltage	4160Y/2400
Secondary Voltage	120/240V (L-N-L)
Frequency	100 Hz
Temperature Rise	65°C
Insulation Rating	Class E Insulation - 120°C, 248°F
Cooling Class	KNAN; Self-Cooled
Efficiency Standard(s)	Meets DOE 2016 Standards, Meets CSA Standards Meets ANSI/IEEE Standards
K-Factor Rating (Harmonic Mitigation)	K-1 (Standard)
Insulation Fluid	FR-3, Non-PCB Fluid
Winding Material	Copper
Ambient Temperature Rating	40°C
Ambient Operating Temperature Range	-40°C to +40°C (-50°F to +104°F)
Dimensions*	24''-W x 27''-D x 42''-H

Drawing

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 3

Structural Features

1. The tank lids have high-voltage porcelain bushings that come with ring terminals, which can accommodate either aluminum or copper cables.
2. The circular sewing structure of the tank cover ensures even stress distribution and reliable sealing.
3. The ring bolts on the tank wall serve as the low-voltage bushing and terminal and are tin-plated.
4. This item comes with a pressure relief valve that is capable of self-sealing.
5. According to ANSI standards, the transformer's suspension hooks at the top and bottom comply.
6. The ground terminal on the tank is a ring bolt ground terminal.

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 4

Testing

Before the single phase pole mounted transformer is delivered, we will arrange a series of tests which help the customers to verify the quality and ensure the safety. Generally we will perform routine tests which include Ratio test, Winding resistance test, No load loss and no load current test, Applied voltage and induction voltage tests, Leakage test and so on. We will forward the test report by specifying all these tests result with the signature of a professional engineer on the test document. Beside the routine tests, there are other optional tests such as Resistance test, Temperature rise test, Sound level test and so on.

Specifications

10kva-333kva Single-phase oil immersed transformer
Rated Cap acity(kVA)	High	Low Voltage(v)	Connection Symbol	Standard	Short-circuit impedance(%)	Efficiency
	Voltage(v)					(%)
10	4160 7200 12000 12470 13200 13800 19920 24940 34500	110 220 230 400 480	II0,II6	IEEE/ANSI/ DOE	1.8-4%	98.7
15						98.82
25						98.95
37.5						99.05
50						99.11
75						99.19
100						99.25
167						99.33
250						99.39
333						99.43

Production process

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 5

50kva Power Pole Transformer Overhead Distribution Dual Windings Transforme 4160Y To 120V UL Certified 6

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.

Tags:

pole mounted distribution transformer

single phase pole mounted transformer

Oil Immersed Distribution Transformer
