Oil Type Transformer
>
Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE

Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE

Brand Name: WINLEY
Model Number: D-167/12
MOQ: 1unit
Price: $1000-$10000
Packaging Details: Plywood case
Payment Terms: T/T
Detail Information
Place of Origin:
CHINA
Certification:
CE,ISO
Transformer Type:
Pole Mount Distribution Transformer
Capacity:
167 KVA
Insulation Fluid:
Mineral Oil - Non PCB Fluid
Sound Level:
50 DBA
Primary Voltage:
7200/12470GrdY
Secondary Voltage:
277/480V
Temperature Rise:
65°C
Standard:
ANSI / IEEE Standard C57.12.20
Supply Ability:
1000set/month
Highlight:

277/480V Pole Mounted Distribution Transformer

,

12470V Pole Mounted Distribution Transformer

,

ANSI Pole Mounted Distribution Transformer

Product Description

Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V





Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE 0




Normal conditions of use



Altitude cannot exceed: 1000m
Highest ambient temperature: +40°C
Highest daily average temperature: +30°C
Highest annual average temperature: +20°C
Lowest outdoor temperature: -25°C



Application scenarios



It can be used for power supply in rural areas, remote rural areas, outdoor installation, etc.
Transformers operating under special applicable conditions are available upon request.



structure

Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE 1

Main data



Phase Single Phase
Capacity 167 KVA
Primary Voltage 7200/12470GrdY Grounded Wye (2 Wire)
Secondary Voltage 277/480V (L-L-N)
Frequency 60 Hz
Temperature Rise 65°C
Cooling Class ONAN
No Load Loss 350W
Full Load Loss 1410W
Efficiency @ 100% Load 98.95%
Impedance (approx) 3%
Winding Material Copper
Core Material Grain Oriented Steel
Dimensions 38'' x 33'' x 58''
Weight 1542 lb
Ratings
Conforms to ANSI / IEEE Standard C57.12.20



Specifications



10kva-500kva Single-phase oil immersed transformer
Rated Cap acity(kVA) High Low Voltage(v) Connection Symbol Standard Short-circuit impedance(%) Efficiency
Voltage(v) (%)
10 4160
7200
12000
12470
13200
13800
19920
24940
34500
110
220
230
400
480
II0,II6 IEEE/ANSI/ DOE 1.8-4% 98.7
15 98.82
25 98.95
37.5 99.05
50 99.11
75 99.19
100 99.25
167 99.33
250 99.39
333 99.43
500 99.49



Accessories



Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE 2





Production images



Single Phase Pole Mounted Distribution Transformer Step Down 12470V to 277/480V ANSI / IEEE 3



Production process



3150KVA Three Phase Dry Type Isolation Transformer NEMA3R 480V 208V 2

3150KVA Three Phase Dry Type Isolation Transformer NEMA3R 480V 208V 3

3150KVA Three Phase Dry Type Isolation Transformer NEMA3R 480V 208V 4



FAQ



1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
