45KVA Three Phase Power Pole Mounted Distribution Transformer Oil Immersed 12000V

Basic Information
Place of Origin: CHINA
Brand Name: WINLEY
Certification: CE,ISO
Model Number: S-45/12
Minimum Order Quantity: 1unit
Price: $1000-$10000
Packaging Details: Plywood case
Delivery Time: 30days
Payment Terms: T/T
Supply Ability: 1000set/month
Detail Information
Phase: Three Phase Type: Overhead Distribution Transformer
Capacity: 45 KVA Primary Voltage: 12000V
Secondary Voltage: 208Y/120 Frequency: 60Hz
Temperature Rise: 65°C Windings Material: Copper
Efficiency Standard(s): Meets DOE 2016 Standards, Meets ANSI/IEEE Standards Cooling Class: ONAN; Self-Cooled
High Light:

45KVA Power Pole Mounted Distribution Transformer

,

12000V Power Pole Mounted Distribution Transformer


Product Description

45KVA Three Phase Power Pole Mounted Distribution Transformer Oil Immersed 12000V​





WINLEY’s Three Phase Pole Mounted Round Tank is designed for service in areas where three phase power is needed, but space is limited. It provides a cleaner looking service with lower installation cost than a bank of three single phase transformers. Triplex core/coil is the choice for serving electric motor loads especially with frequent motor starts.



45KVA Three Phase Power Pole Mounted Distribution Transformer Oil Immersed 12000V 0



Main data



Transformer Type Overhead Distribution Transformer, Conventional Type
Transformer Polarity Type Subtractive
Phase Three Phase
Capacity 45 KVA
Primary Voltage 12000V
Secondary Voltage 208Y/120 (L-N-L)
Frequency 60 Hz
Temperature Rise 65°C
Insulation Rating Class E Insulation - 120°C, 248°F
Cooling Class ONAN; Self-Cooled
Impedance 3.75%
Efficiency Standard(s) Meets DOE 2016 Standards, Meets ANSI/IEEE Standards
K-Factor Rating (Harmonic Mitigation) K-1 (Standard)
Pulse Drive Rating N/A
Winding Material Copper
Ambient Temperature Rating 40°C
Sound Level 48 dBA
Dimensions* 24''-W x 29''-D x 65''-H
Efficiency 98.70%
Total Load Loss (in watts) +/- 684W



Drawing



45KVA Three Phase Power Pole Mounted Distribution Transformer Oil Immersed 12000V 1



Standard Features



Meets or exceeds current IEEE, NEMA standards.
Triplex core/coil design.
Wet process high voltage bushings.
Molded polymer low voltage bushings.
Tin plated bronze terminals suitable for copper or aluminum connection.
Two tank grounding provisions.
Lightning arrester mounting provisions.
1/2” drain plug.
Automatic pressure relief device.
Mineral oil.
Mild steel tank and bolted cover.
Laser engraved nameplate.
