| Brand Name: | WINLEY |
| Model Number: | TDGC2-3KVA |
| MOQ: | 1unit |
| Price: | $20-$8000 |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T |
3KVA Lighting Three Phase Voltage Regulator Variac Rotary Knob 0-250VAC
Features:
1) Manually Operated Rotary Knob to control output voltage, by means of a control button on the shaft of the voltage regulator (Variac) which allows to act on the brush and achieve the desired voltage.
2) The voltage can be smoothly varied between turns as the brush has a relatively high resistance (compared with a metal contact) and the actual output voltage is a function of the relative area of brush in contact with adjacent windings.
Specification:
| Item | Description | Value |
| 1 | Capacity |
3000VA |
| 2 | Output Current | 12A |
| 3 | Output | 0~250V AC |
| 4 | Frequency | 50/60Hz |
| 5 | Input | 220V AC |
| 6 | Insulation Resistance | >5MΩ |
| 7 | No. of Phase | Single-Phase |
| 8 | Winding Material | 100% Copper |
| 9 | Max.Temperature | 60℃ |
| 10 | Insulation Class | Class B (130 ℃) |
| 11 | IP/NEMA Rating | IP20 |
| 12 | Variable Operation | Manually Operated Rotary Knob |
| 13 | Portable Carrying Grip | Provided |
| 14 | Pollution Rating | Class III |
| 15 | Analog Voltmeter Display | Provided |
| 16 | Housing Material | Shock-Proof Metal |
| 17 | Voltage Setting | Manual Control |
| 18 | Standards | VDE0550, IEC204-1, IEC61588, EC439 |
| 19 | Sample Service | Pay to Provide |
| 20 | Quality Assurance | 24Months |
FAQ
1. Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
2. Q: What is the lead time?
A: Sample time 3-7 days, we usually ship by DHL, UPS, FedEx,etc. Mass production time 7-25 days.
3. Q: How long is the warranty?
A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.
4. Q: Is OEM/ODM available?
A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.
Customized services:
a. Customized color and special function.
b. Customized box.
c. Print customer's logo(MOQ:≥10pcs).
d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.
5. Q: How to control the products quality?
A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
|
|
