45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure

Brand Name:	WINLEY
Model Number:	SG-30KVA
MOQ:	1unit
Price:	$500~$60000/Unit
Packaging Details:	Plywood case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO,CE,UL/cUL

Model:

SG-30KV

Phase:

Three Phase

Rated Power:

30KVA

Primary Voltage:

400Y/231V With 2x2.5% FCAN,4x2.5% FCBN Taps

Secondary Voltage:

208Y/120V

Insulation Class:

Temperature Rise:

<150℃

Frequency:

50/60Hz

Supply Ability:

1000units/month

Product Description

30kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure

Overview

The SG-30KVA Three-phase Dry-type Transformer is a reliable, compact, and efficient power transformer designed for commercial and industrial applications. Built with aluminum windings and an air-cooled design, this transformer provides stable three-phase power conversion with excellent electrical insulation and safety performance. It is optimized for indoor installations where fire safety, low maintenance, and high reliability are required.

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 0

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 1

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 3

Key Specifications

Model: SG-30KVA
Name: Three-phase Dry-type Transformer
Rated Power: 45 KVA
Phase: Three
Frequency: 50/60 Hz
Winding Material: Aluminum
Cooling Method: Air cooling (dry-type)
Insulation Class: Class C
Temperature Rise: < 150°C
Electrical Ratings
Input (Primary) Voltage: 400Y/231 V
Tap changer configuration: 2 × 2.5% (FCAN), 4 × 2.5% (FCBN)
Input (Primary) Current: 43.3 A
Output (Secondary) Voltage: 208Y/120 V
Output (Secondary) Current: 83.2 A
Protection, Testing & Insulation
Withstand Voltage Test (60 seconds):
Primary to Secondary: 2500 V / 60 s
Primary to Grounding: 2500 V / 60 s
Secondary to Grounding: 2500 V / 60 s
Insulation Resistance:
Primary to Secondary: > 100 MΩ
Primary to Grounding: > 100 MΩ
Secondary to Grounding: > 100 MΩ
Induced Withstand Voltage: 125 Hz / double voltage / 1 min (as specified)
Grounding Resistance: withstands 25 A with grounding resistance < 100 mΩ

Technical drawings

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 4

Features & Benefits

Safe and Fire-resistant: Dry-type construction eliminates oil, reducing fire risk and environmental hazards.
High Insulation & Dielectric Strength: Tested for high withstand voltage and high insulation resistance to ensure long-term reliability.
Tap Changer Flexibility: Multiple taps (2×2.5% and 4×2.5%) allow for voltage adjustment to compensate for system variations.
Low Maintenance: Air cooling and aluminum windings reduce maintenance requirements and operating costs.
Wide Frequency Compatibility: Supports both 50 Hz and 60 Hz systems for global applicability.

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 5

Typical Applications

Commercial buildings and office complexes
Industrial plants and manufacturing facilities
Data centers and telecommunications sites
Hospitals and educational institutions
Any indoor installations requiring dependable, low-maintenance three-phase power transformation

Specification

Model (kva)	Primary Voltage	Secondary Voltage	Coupling group tab	Shape dimension			Mounting dimension		K*J	The box dimension
Model (kva)	Primary Voltage	Secondary Voltage	Coupling group tab	Bmax	Dmax±5	Emax	A	C±5	K*J	Bmax	Dmax±5	Emax
SG-10KVA	660 400 380 200	380 220 110 36	Yyn0 Y/d D/y D/d	360	180	305	215	140	10*20	450	360	480
SG-15KVA				360	200	335	215	155	10*20	450	360	480
SG-20KVA				420	210	350	250	170	10*20	490	400	540
SG-30KVA				420	230	380	250	190	10*20	490	400	540
SG-50KVA				680	350	550	420	220	10*20	800	510	840
SG-80KVA				750	400	620	480	250	10*20	850	510	840
SG-100KVA				780	420	650	500	250	10*20	900	550	890
SG-300KVA				180	95	185	100	75	6*14
SG-500KVA				180	95	185	100	75	6*14
SG-1000KVA				180	110	185	100	90	6*14
SG-2000KVA				230	125	205	130	100	9*16
SG-3000KVA				240	145	215	130	120	9*16
SG-4000KVA				240	155	235	130	130	9*16
SG-5000KVA				320	160	255	180	115	10*20	400	330	480
SG-6000KVA				300	165	280	180	140	10*20	400	330	480

Production process

45kva Three Phase Dry Type Transformer Distribution Low Voltage Multi-Tap 400v To 208v Mechanical Terminals Nema 3r Electrical Enclosure 6

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Sample time 3-7 days, we usually ship by DHL, UPS, FedEx,etc. Mass production time 7-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo(MOQ:≥10pcs).

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
