2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57

Brand Name:	WINLEY
Model Number:	ZGS-2100/13.8
MOQ:	1unit
Price:	$5000-$150000
Packaging Details:	Plywood case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

UL/cUL,CE,ISO

Type:

Pad Mounted,Radial Feed

Capacity:

2100KVA

Primary Voltage:

13800V

Secondary Voltage:

480Y/277

Impedance:

5.0~7.0

Material:

Aluminum

Vector Group:

UL/cUL Certification:

UL-US-2431836-0, UL-CA-2423202-0

Supply Ability:

1000set/month

Product Description

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57

Three Phase Pad Mounted Transformerl are made with the highest quality materials and are widely used in residential complexes, commercial centers, airports, stations, schools, solar boost, manufacturing facilities, industrial applications and crypto mining/bit coin mining.

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57 0

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57 1

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57 2

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57 3

Why choose us

WINLEY produces a full range of three phase pad mounted transformers with a capacity of 45kva-5500KVA and a voltage of up to 34.5KV. The products meet or even exceed the standards of DOE 2016, IEEE/ANSI, CSA, IEC, NEMA, etc.
The three phase pad mounted transformer produced by WINLEY has obtained UL/cUL certification (Certificate Number: UL-US-2431836-0, UL-CA-2423202-0), and can apply for UL (partner authorization) according to customer requirements.
Our products are exported to North America, South America, the Philippines and other places in large quantities. We have rich experience in design and production, professional and reliable after-sales service, and can deliver goods quickly within 7-35 days.

2100Kva Three Phase Pad Mounted Transformer Oil Immersed Distribution 13800 To 480V IEEE C57 4

Main data

No.	Particulars	Unit	Specification
1	Type	~	pad mounted,radial feed
2	Rated capacity	kVA	2100
3	No. of Phase	~	3
4	Primary voltage	V	13800
5	Primary termination	~	15kV class, BIL95kV, 200A well&insert
6	Secondary voltage	V	480Y/277
7	Secondary connection	~	10-hole spade
7	Tapping type	~	off-circuit tapping
8	Tapping range	%	±2*2.5%
9	Cooling method	~	ONAN
10	Rated frequency	Hz	60
11	Vector group	~	Dyn1
12	Insulation class	~	A (105℃)
13	Temperature rise	K	65
14	Off-load loss	W	2250
15	On-load loss (85℃)	W	19800
16	Impedance	%	5.0~7.0
17	Winding material	~	Aluminum
18	Core material	~	silicon steel
19	Cooling material	~	Mineral oil
20	Housing material	~	coated steel (Munsell bell green)
23	Service condition	~	indoor or outdoor
24	Sea level	M	≤1000
25	Standard	~	IEEE C57.159

Technical drawings

Specification

Rated Power (KVA)	High Voltage (KV)	Low Voltage (V)	No-load Loss (W)	On-load Loss (W)	Height (mm)	Depth (mm)	Width (mm)	Weight (kg)	Weight (Lbs)
75KVA	34.5KV 4.160KV 12.47KV 13.2KV 13.8KV 24940GrdY/14400 1247Grdy/7200 4160GrdY/2400 or others	277V 347V 480V 600V 120/240V 208GrdY/120 415GrdY/240 480GrdY/277 600Y/347	180	1250	1430	910	1930	645	1422
150KVA			280	2200	1530	980	1510	989	2180
300KVA			480	3650	1680	1080	1660	1415	3119
500KVA			680	5100	1790	1160	1810	1905	4200
750KVA			980	7500	2030	1300	2030	2755	6074
1000KVA			1150	10300	1854	1549	1651	3235	7132
1500KVA			1640	14500	2150	1570	2210	5835	12864
2000KVA			2160	20645	2220	1600	2380	6430	14175
2500KVA			2680	23786	2330	1650	3070	8865	19544
3000KVA			3300	30300	2460	1850	3260	11300	24912
3735KVA			4125	37875	2680	2060	4080	14400	31746
