1500Kva Three Phase Pad Mounted Transformer Oil Immersed 4160V Meets DOE 2016 ANSI/IEEE Standards

Why choose us

• High-Quality Transformers: WINLEY offers a full range of three-phase pad-mounted transformers (45kVA-5500kVA, up to 34.5kV) that meet or exceed industry standards like DOE 2016, IEEE/ANSI, CSA, IEC, and NEMA.
• Certified and Customizable: Our transformers are UL/cUL certified (UL-US-2431836-0, UL-CA-2423202-0) and can be UL-authorized based on customer requirements.
• Experienced and Reliable: With extensive experience exporting to North & South America and the Philippines, we provide professional after-sales service and fast delivery within 7-35 days.

Main data

STRUCTURE

Drawing

Features

• Loadbreak high-voltage bushing inserts or externally clamped integral (one piece) high-voltage bushings for dead-front applications.
• Externally-clamped porcelain high-voltage bushings with eyebolt connectors for live-front applications.
• Low-voltage connectors, including various screw-on or slip-on types.
• Lightning arrester mounting provisions.
• Externally operable non-loadbreak high-voltage tap switch with one of the following tap ranges: four 2.5%taps above normal; or four 2.5% taps below normal; or two 2.5% taps above and two 2.5%taps below normal; or taps at13800/13200/12870/ 12540 for transformers with a nominal high-voltage rating of 14400 (may not be available in combination with dual high-voltage switch).
• Externally operable dual high-voltage switch (may not be available in combination with high-voltage tap switch).
• Externally operable two-position or four-position high-voltage loadbreak switch.
• Secondary termination:Externally clamped bushings with NEMA 4-hole, 6-hole, 8-hole, 10-hole or12-hole spades Spade supports are available. They are provided for 8-hole spades and larger.
• Draw-out full-range current limiting fuses in dry-well canisters; with or without interlocking loadbreak switch.
• Arc Strangle* fused disconnect.
• under-oil, elbow, or panel-mounted types (panel-mounted types are available on compartmental live-front units only).
• Drip shields for use with draw-out expulsion fuse.
• High capacity pressure relief device mounted on tank cover.
• Drain valve with sampling device.
• Total stainless steel or hybrid.(mild steel/stainless steel construction)

Specification

Application

Their sealedhigh-voltage and low-voltage safely compartments ensure their safe operalion and reduce the risk of accidents, making themideally suited for use in residential applications, tourist sites, hotels and other buildings.
