Three Phase Pad Mounted Transformer

Three Phase Pad Mounted Transformer
July 31, 2025
Category Connection: Three Phase Pad Mounted Transformer
Chat Now Contact Us
Tags:
#Pad Mounted Transformer #3 phase pad mounted transformer #three phase pad mounted transformer
Brief: Discover the UL listed 1500Kva Three Phase Pad Mounted Transformer, designed for power system distribution with multi-voltage support from 13.8KV, 13.2KV, 12.47KV to 480V, meeting ANSI standards. Ideal for loop feed applications, this oil-filled transformer ensures reliable performance.
Related Product Features:
  • UL listed and cUL certified, meeting DOE 2016, IEEE/ANSI, CSA, IEC, and NEMA standards.
  • 1500 kVA rated capacity with a 3-phase system for efficient power distribution.
  • Primary voltage of 13.2 kV (Grounded Wye) and secondary voltage of 480Y/277 V (Wye-N).
  • Designed for loop feed applications with a tapping range of 14400V to 11500V.
  • Cooling method: ONAN, with a temperature rise of 65℃ and impedance of 5.75%.
  • Constructed with aluminum windings and silicon steel core for durability.
  • Suitable for both indoor and outdoor use, with a sea level limit of ≤1000M.
  • Comes with standard features like iron core, winding, fuel tank, and optional accessories.
Faqs:
  • What certifications does this transformer have?
    The transformer is UL/cUL certified (Certificate Numbers: UL-US-2431836-0, UL-CA-2423202-0) and meets DOE 2016, IEEE/ANSI, CSA, IEC, and NEMA standards.
  • What is the lead time for this product?
    Mass production typically takes 15-25 days, with delivery possible within 7-35 days depending on order size and customization.
  • Can the transformer be customized?
    Yes, OEM/ODM services are available, including customized colors, special functions, packaging, and logo printing. Custom designs must be confirmed before production.
  • What is the warranty period for this transformer?
    The warranty is 24 months from the Bill of Lading date. Free service and technical support are provided for any accessory problems, with easily damaged accessories supplied based on product quantity.
